8. Installation mode
8. INSTALLATION MODE
Overview
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
8.1 Build-up
Build-up of the installation mode.
The installation menu is build-up in two parts which are connected together with the ’more’ item. If the desired item is not in the list
of the displayed menu, select ’more’ with the cursor key and push ENTER to display the other items in the installation menu.
8.2 Start up installation mode
Start up
1. Push the cursor key
↑
or
↓
to highlight Installation. (menu 8-1)
2. Press ENTER.
One of the following installation mode menus will be displayed. (menu 8-2)
ADJUSTMENT MODE
Select a path from below :
AUTO IMAGE
RANDOM ACCESS
INSTALLATION
SERVICE
Source 01
Select with
↑
or
↓
then
Menu 8-1
INSTALLATION
INPUT SLOTS
NO SIGNAL
LENS
TEXT BOX POSITION
QUICK ACCESS KEYS
START UP MODE
NETWORK CONFIGURATION
more ...
Select with
↑
or
↓
then
Menu 8-2
INSTALLATION
800 PERIPHERALS
CONFIGURATION
OSD COLOR
INTERNAL PATTERNS
SWITCHING MODE : [BLANKING]
SHUTTER
more ...
Select with
↑
or
↓
then
Menu 8-3
8.3 Input slots
What can be done ?
The input configuration of the variable inputs is shown in the Input slots menu.
R5976182 BARCOREALITY 6500 30012001
