B. BARCO Control Manager
B.4.5 Image Enhancement
Changing noise reduction & dynamic color
Noise reduction (reduces noise and pixel jitter in all video and data sources) and dynamic color depth (increases color contrast for
all video and data sources) can be changed by :
1. Moving with the mouse the slide bar up or down (image B-9)
Or ,
Clicking on the up or down arrow on the edges of the slide bar.
A value indication for the setting will be given just below the slide bar of the adjustment.
Image B-9
Image Enhancement settings
Click on init to return to the default value.
CTI
Color transient improvement
CTI and decoding toggle
1. Click with the mouse on the ’on’ or ’off’ button of the CTI or decoding item to switch on or off.
What is decoding
The possibility is offered to decode the NTSC video signals via the default American IRE standard or via the European EBU standard.
Decoding a NTSC signal using the European EBU standard may result in a greenish tint.
While changing one off these enhanced image settings with the RCU, the values indicated on the enhanced
image settings web page will only be changed after 15 min.
B.4.6 Lens adjustment
How to change
The lens adjustment can be done with lens web page .
98 R5976182 BARCOREALITY 6500 30012001
