6. Auto Image Adjustment
6. AUTO IMAGE ADJUSTMENT
6.1 Start up
Why auto image ?
Auto image will center the image on the LCD panel when a file is loaded.
How to start up ?
Handle as follow to start up the auto image function :
1. Push the cursor key ↑ or ↓ to highlight Auto Image. (menu 6-1)
2. Press ENTER.
The auto image menu will be displayed. (menu 6-2)
ADJUSTMENT MODE
Select a path from below :
AUTO IMAGE
RANDOM ACCESS
INSTALLATION
SERVICE
Source 01
Select with ↑ or ↓
then
to return.
Menu 6-1
AUTO IMAGE
ADJUST
ACTION : FULL AUTOMATIC
Select with ↑ or ↓
then
to return.
Menu 6-2
With auto image, it is possible to switch the auto image function ’on’ or ’off’ and to adjust an existing image
when the auto image function is off.
6.2 Adjust
What can be done ?
By selecting Adjust the image will be centered on the active area of the LCD surface. The centering will be done by adapting the
values for ’pixel start’, ’pixel end’, ’line start’ and ’line end’.
How to center the image ?
To center the image :
1. Push the cursor key
↑
or
↓
to highlight Adjust. (menu 6-3)
2. Press ENTER to activate.
The image will be centered on the LCD surface.
This is the same function as the ? key on the remote control when in operational mode.
The menu is automatically exited. The adjustment values will be saved when switching to another source.
AUTO IMAGE
ADJUST
ACTION : FULL AUTOMATIC
Select with ↑ or ↓
then
to return.
Menu 6-3
R5976182 BARCOREALITY 6500 30012001 39
