8. Installation mode
How to change ?
To set up the shutdown time, handle as follow:
1. Push the cursor key
↑
or
↓
to highlight No Signal. (menu 8-10)
2. Press ENTER to select.
The no signal menu will be displayed. (menu 8-11)
3. Push the cursor key ↑ or ↓ to highlight Shutdown Time.menu 8-11
4. Push the cursor key ↑ or ↓ to change the digits.
Or ,
Enter the digits directly with the digit keys on the RCU.
INSTALLATION
INPUT SLOTS
NO SIGNAL
LENS
TEXT BOX POSITION
QUICK ACCESS KEYS
START UP MODE
NETWORK CONFIGURATION
more ...
Select with
↑
or
↓
then
to return.
Menu 8-10
NO SIGNAL
COLOR [Blue]
SHUTDOWN [off]
Shutdown time: 5 min
Select with ↑ or ↓
then
to return.
Menu 8-11
8.5 Lens adjustment
What can be done ?
All lens adjustments are motorized and can be adjusted with the RCU.
The following items can be adjusted:
• zoom/focus
• shift
Zoom/Focus adjustment of the lens.
1. Push the cursor key
↑
or
↓
to higlight Lens. (menu 8-12)
2. Press ENTER to select.
The adjustment pattern will be displayed.
With the TEXT key it is possible to toggle between the internal adjustment pattern or the connected source.
3. Push the cursor key
↑
or
↓
to zoom and
←
or
→
to focus the image.
Note: The zoom/focus function is only applied when a motorized zoom lens is mounted.
4. When finished, press EXIT to return to the installation menu or press ENTER to go to the shift function.
INSTALLATION
INPUT SLOTS
NO SIGNAL
LENS
TEXT BOX POSITION
QUICK ACCESS KEYS
START UP MODE
NETWORK CONFIGURATION
more ...
Select with
↑
or
↓
then
to return.
Menu 8-12
