7. Random Access
Adjusting the blanking.
1. Push the cursor key
↑
or
↓
to highlight Blanking. (menu 7-47)
2. Press ENTER to display the blanking menu. (menu 7-48)
3. Push the cursor key ↑ or ↓ to highlight the desired blanking.
4. Press ENTER to start up the chosen blanking.
5. Use the cursor keys to adjust the blanking.
GEOMETRY
SHIFT
SIZE
SIDE KEYSTONE
BLANKING
ASPECT RATIO [5:4]
OPTIONS
Select with ↑ or ↓
then
to return.
Menu 7-47
BLANKING
TOP
BOTTOM
LEFT
RIGHT
Select with ↑ or ↓
then
to return.
Menu 7-48
7.5.7 Aspect Ratio
Purpose
To force the projector in a typical aspect ratio. E.g. projecting a 4:3 image in a 16:9 aspect ratio.
How to set up the desired aspect ratio ?
1. Push the cursor key ↑ or ↓ to highlight Aspect Ratio. (menu 7-49)
2. Press ENTER to scroll between [5:4] or [4:3] or [16:9].
GEOMETRY
SHIFT
SIZE
SIDE KEYSTONE
BLANKING
ASPECT RATIO [5:4]
OPTIONS
Select with ↑ or ↓
then
to return.
Menu 7-49
7.5.8 Options
What is possible ?
Within the Geometry options menu, it is possible to set up the side keystone for the active file only or for all files equal.
[No] = keystone has to be adjusted file per file.
[Yes] = keystone correction the same for all installed files.
60 R5976182 BARCOREALITY 6500 30012001
