8. Installation mode
To view or the change the input configuration.
1. Push the cursor key
↑
or
↓
to highlight Input Slots. (menu 8-4)
2. Press ENTER to select.
The input slots menu will be displayed. (menu 8-5)
INSTALLATION
INPUT SLOTS
NO SIGNAL
LENS
TEXT BOX POSITION
QUICK ACCESS KEYS
START UP MODE
NETWORK CONFIGURATION
more ...
Select with ↑ or ↓
then
to return.
Menu 8-4
INPUT SLOTS
SLOT SELECTOR [Automatic]
x 1. RGB [HV&VS]
- 2. RGB [HV&VS]
- 3. VIDEO
- 4. S-VIDEO
- 5. DIGITAL INPUT
- 6. IEEE 1394
Select with ↑ or ↓
to toggle
to return.
Menu 8-5
The black indicated inputs are selectable and changeable. The gray indicated inputs are fix inputs and are not
changeable.
The indication in front of the digit means :
x : valid signal connected to the input.
- : no valid signal connected to the input.
Possible results for the input slots.
Source Indication
Video or S-Video Video
S-video
RGB analog RGB-CV : separate sync is composite video on H/C input
RGB-HS&VS: separate sync is horizontal and vertical sync
RGB-CS : separate sync is composite sync
RGB-SOG : sync on green
Component Video Component video
IEEE 1394 IEEE1394
SDI Digital input
What if a switcher is connected to the projector ?
If a RCVDS (switched on) or VS05 is connected to the projector, it will be also indicated on the menu by adding +800 peripheral.
If no 800 peripheral indication is made on the menu, there are still two possibilities, no RCVDS or VS05 connected or RCVDS is
switched off.
When a 800 peripheral is connected to the projector, the input slots are not accessible with the cursor key to toggle their function.
8.4 No Signal
What will happen ?
If there is no signal connected to the projector,
• The background color can be black or blue
• The projector can shutdown after a certain time.
