7. Random Access
Start up
1. Push the cursor key
↑
or
↓
to highlight Random Access. (menu 7-1)
2. Press ENTER.
ADJUSTMENT MODE
Select a path from below :
AUTO IMAGE
RANDOM ACCESS
INSTALLATION
SERVICE
Source 01
Select with ↑ or ↓
then
to return.
Menu 7-1
7.2 Picture Services
7.2.1 File annotation
How a file is built up
The file notation on a menu is built up in different parts. Let us have a look to these parts.
Take the following notation : xxxxxxxx.eee n ppppXppppi
xxxxxxxx base name, 8 characters
eee file extension
first character C : custom made file
first character S : standard file
The second and third character is used for a following number (= file
index). The file index for custom files : 00 to 63.
n source number
ppppXpppp active pixel rating
i i or blank
i = interlaced file
blank = not interlaced
Table 7-1
7.2.2 Possible file manipulations
Connecting a new source.
Before using a new source, a correct file has to be installed. The projector’s memory contains a list of files corresponding to the most
used sources. When the new source corresponds with one of these files, the file can be loaded and saved for future use. When
there is a little difference, the file can also be loaded and then edited until the source specs are reached.
file loading can be done automatically (see File options, page 50, in this chapter). Files with a ~ in front of the
file name are temporary files. These files will be deleted when switching to another source.
