7. Random Access
Size adjustment
1. Push the cursor key
↑
or
↓
to highlight Size. (menu 7-45)
2. Press ENTER to select.
3. Push the cursor key ↑ or ↓ to size the image in a vertical direction.
Push the cursor key ← or → to size the image in a horizontal direction.
GEOMETRY
SHIFT
SIZE
SIDE KEYSTONE
BLANKING
ASPECT RATIO [5:4]
OPTIONS
Select with ↑ or ↓
then
to return.
Menu 7-45
7.5.5 Side Keystone
What can be done ?
The side keystone adjustment is used to align the image if the projector is mounted at a non standard projector angle.
Aligning the keystone.
1. Push the cursor key
↑
or
↓
to highlight Side keystone. (menu 7-46)
2. Press ENTER to select.
3. Push the cursor key ↑ or ↓ to adjust the keystone of the image.
When the upper part of the image is wider than the lower part of the image, push the cursor key
←
. The number indication below
the bar scale will be negative.
When the upper part of the image is smaller than the lower part of the image, push the cursor key
→ . The number indication
below the bar scale will be positive.
GEOMETRY
SHIFT
SIZE
SIDE KEYSTONE
BLANKING
ASPECT RATIO [5:4]
OPTIONS
Select with ↑ or ↓
then
to return.
Menu 7-46
7.5.6 Blanking
What can be done ?
Blanking adjustments affect only the edges of the projected image and are used to frame the projected image on to the screen and
to hide or black out unwanted information (or noise). A ’0’ on the bar scale indicates no blanking.
Which blanking adjustments are available ?
• top blanking
• bottom blanking
• left blanking
• right blanking
