8. Installation mode
8.7 Quick Access Keys
8.7.1 What are Quick Access Keys?
What can be done with these keys?
The function keys on top of the RCU can be associated with an adjustment item in one of the adjustment menus. Each item which is
not password protected or does not have a key on the RCU can beassociated to a function key. This key allows then a quick access
to the adjustment function.
Factory programmed functions.
F1 color depth
F2 noise reduction
F3 configuration
F4 lens adjust zoom/focus
F5 lens adjust shift
8.7.2 Getting an overview
Overview
To get an overview, handle as follow :
1. Push the cursor key
↑
or
↓
to highlight Quick Access Keys. (menu 8-16)
2. Press ENTER to select.
The Quick Access Keys menu will be displayed. (menu 8-17)
INSTALLATION
INPUT SLOTS
NO SIGNAL
LENS
TEXT BOX POSITION
QUICK ACCESS KEYS
START UP MODE
NETWORK CONFIGURATION
more ...
Select with ↑ or ↓
then
to return.
Menu 8-16
QUICK ACCESS KEYS
F1 : DYNAMIC COLOR DEPTH
F2 : NOISE REDUCTION
F3 : CONFIGURATION
F4 : LENS ADJUST ZOOM/FOCUS
F5 : LENS ADJUST SHIFT
Note :
’?’ : auto image adjust
’*’ : lens adjustment
Menu 8-17
8.7.3 Programming the Quick Access Keys.
How to program?
1. Scroll through the menus until the desired menu is active.
2. Push the desired function key for 3 seconds.
The message ’Quick access to this menu with Fx’, where x is the digit of the selected function key. If the selected menu is not a
valid menu for the quick access keys the next message will be displayed : "Quick access to this menu impossible".
8.8 Start Up mode
What can be done?
1. During start up, the projector can show first the identification screen or a blank screen.
2. The projector can start up with auto power. The projector starts up in the same power condition as it was before power supply
was interrupted.
