GS1 DataBar Expanded (RSS Expanded)
Symbology number:
31
Valid characters:
“A”..”Z”, “a”..”z”, “0”..”9” + ISO 646
character set
Quiet zone:
none required (1X recommended)
Module width:
--
Print ratio:
1:2:3:4:5:6:7:8:9:1:2:3:4:5:6:7:8:9
Ratio format:
1B:2B:3B:4B:5B:6B:7B:8B:9B:
1S:2S:3S:4S:5S:6S:7S:8S:9S
Default check digit:
None (eCDNone).
Possible check digits:
Modulo 10 (eCDMod10). EAN-14
(eCDEAN14)
Size:
Numeric: 74 digits
Alphanumeric: 41 characters
ABab+
This is a variable length symbology. It encodes up to 74 numeric or 41 alphabetic characters. Data
should be encoded with Application Identifiers (AIs). Omni-directional scanning is possible.
6.4.7
GS1 DataBar Expanded Stacked (RSS Expanded Stacked)
Symbology number:
81
Valid characters:
“A”..”Z”, “a”..”z”, “0”..”9” + ISO 646 char
set
Quiet zone:
none required (1X recommended)
Module width:
--
Print ratio:
1:2:3:4:5:6:7:8:9:1:2:3:4:5:6:7:8:9
Ratio format:
1B:2B:3B:4B:5B:6B:7B:8B:9B:
1S:2S:3S:4S:5S:6S:7S:8S:9S
Default check digit:
None (eCDNone).
Possible check digits:
Modulo 10 (eCDMod10). EAN-14
(eCDEAN14)
Size:
--
This is the stacked version of GS1 DataBar Expanded. The number of data segments per row can
vary between 4 and 22. The default number of data segments is 4.
6.5 EAN.UCC Composite Symbologies
6.5.1
Data Input
►
Please note: For all Composite Symbologies the vertical bar “|” character is used to separate
the data of the linear symbol and the 2D composite component.
►
Example: 1234567890123
|
TEC-IT
6.5.2
Data Capacity of EAN.UCC Composite Symbols
6.5.2.1
Linear Component
EAN-128:
up to 48 digits
EAN/UPC:
8, 12 or 13 digits
RSS Expanded: up to 74 digits
Other RSS
16 digits (2 digits AI01 + 14 digits GTIN)
6.5.2.2
2D Component
CC-A
up to 56 digits
CC-B
up to 338 digits
CC-C
up to 2361 digits
