T EC - I T B a r c o d e So f t w a re R e f e re n c e
6.1.49 Italian Postal Code 2 of 5
Symbology number:
94
Valid characters:
“0”..”9”
Quiet zone:
left/right: 10X, min. ¼ inch
Module width:
X>= 0.19 mm
Standard print ratio:
1:3:1:3
Ratio format:
1B:2B:1S:2S
Default check digit:
None (eCDMod10ItlPst25)
Symbol size:
--
Italian Postal Code 2 of 5 is based upon Code 2 of 5 Interleaved, but it is limited to 12 digits (11
usable digits + 1 modulo 10 check digit)..
6.1.50 ITF-14
ITF-14 encodes the GTIN-14, this is a 14-digit number used to identify trade items at various
packaging levels (also referred as GTIN).
ITF-14 is based on the Code 2 of 5 Interleaved symbology. It encodes 14 digits (13 usable digits + 1
modulo 10 check digit). The check digit method complies to the EAN-14 method.
ITF-
14 uses “Bearer Bars”, these are horizontal or surrounding bars, to prevent misreads. The
vertical bearer bars must have at least 10 modules distance to the barcode (this is why you have to
adjust a minimum of 12 for the quiet zone to see a vertical bearer bar in TEC-IT Software).
6.1.51 Japanese Postal Code
Symbology number:
76
Valid characters:
“0”..”9”, “A”..”Z”, “-“,
7 digits (ZIP code) + additional data
Quiet zone:
left/right/top/bottom: 2 mm
Module width:
--
Standard print ratio:
1:1
Ratio format:
1B:1S
Default check digit:
Automatic (symbology specific).
Symbol size:
--
1234567
This code is used by the Japanese Postal system. You can encode 7 digits followed by block and
street number (uppercase alphanumeric). The special compaction mode of Japanese characters
can be enabled on demand (
Format
p
arameter “J”) – see below.
This barcode symbology supports two methods to provide the barcode data (with and without data
–
extraction from the Japanese Address B Field).
6.1.51.1 Direct Encoding Mode
Description
Value
Format Property
“” (default=empty)
Postal code
2730102
(no hyphen „-„)
Address B
3-20-5B604
Barcode text
Postal code + Address B (no space between)
Barcode text
2730102
3-20-5B604
Encoded data in the symbol
27301023-20-5B604
