T EC - I T B a r c o d e So f t w a re R e f e re n c e
With:
Character
Description
Data Type
Length
+/
HIBC Provider Applications Standard Flag
“+/”
2
F*
„Where“ Flag
Alpha
1 or 3
G*
„What“ Flag
Alpha
1 or 3
D
Application Data
Alphanumeric
1-15
C
1
Check Digit (mod 43) - equal to the "Link Character" of the Second
Data Structure.
1
Table 23: HIBC PAS
– Single/First Data Structure
The First Data Structure is specified as follows
+/1F*G*DDDDC
1
It is much the same as the Single Data Structure but has “1” as prefix.
The Second Data Structure is defined as
+/2DDDDC
1
C
2
With:
Character
Description
Data Type
Length
+/
HIBC Provider Applications Standard Flag
“+/”
2
2
"2" indicates that this is the second data structure
“2”
1
D
Application Data
Alphanumeric
1-15
C
1
Check Digit (mod 43) - conforms to the check digit in the First Data
Structure.
1
C
2
Check Digit (mod 43) - equal to the "Link Character" of the Second
Data Structure.
1
Table 24: HIBC PAS
– Second Data Structure
The Combined Data Structure (First and second data structure in one piece) is defined as
+/F*G
1
*D
1
D
1
D
1
/G2*D
2
D
2
D
2
C
With:
Character
Description
Data Type
Length
+/
HIBC Provider Applications Standard Flag
“+/”
2
F*
„Where“ Flag
Alpha
1 or 3
G
1
*
„What“ Flag for D
1
Alpha
1 or 3
D
1
First Application Data
Alphanumeric
1-15
/
Separator Character between First and Second Data Structure
“/”
1
G
2
*
„What“ Flag for D
2
Alpha
1 or 3
D
2
Second Application Data
Alphanumeric
1-15
C
Check Digit (mod 43
1
Table 25: HIBC PAS
– Combined Data Structure
