T EC - I T B a r c o d e So f t w a re R e f e re n c e
EAN-128 or Code-128
Data Matrix: a special FNC1 codeword is
inserted
\F
Inserts a Gs (Group Separator) or ASCII 1DHex.
Don‟t encode the \x1d directly!
PDF417, MaxiCode and in QR-Code
QR.Code: When using format UCC/EAN a
Gs is inserted in Byte Mode, a % is
inserted in alphanumeric mode.
\E
ECI (Extended Character Interpretation). Used for defining
the character set (code page) for the encoded data
– contact
us to get further information.
MaxiCode, Data Matrix and QR-Code,
PDF417, MicroPDF417
\EB, \EE
Special ECI identifiers for nesting ECIs.
\EB
(ECI Begin)
opens a nesting level,
\EE
(ECI End) closes it.
QR-Code
\G
GLI (Global Language Identifier), similar to ECI (see
\E
).
PDF417
\210
FNC1
Code128, EAN-128, UCC128, Codablock-
F
\211
FNC2
Code128, EAN-128, UCC128, Codablock-
F
\212
FNC3
Code128, EAN-128, UCC128, Codablock-
F
\213
FNC4
Code128, EAN-128, UCC128, Codablock-
F
\x11
DC1
Code93, Code93Ext
\x12
DC2
Code93, Code93Ext
\x13
DC3
Code93, Code93Ext
\x14
DC4
Code93, Code93Ext
\x1e
Rs (Record Separator), ASCII 1EHex
PDF417, QR-Code, DataMatrix, MaxiCode
(Mode 3,4 SCM)
\x1d
Gs (Group Separator), ASCII 1DHex
PDF417, QR-Code, DataMatrix, MaxiCode
(Mode 3,4 SCM)
\x04
Eot (End of Transmission), ASCII 04Hex
PDF417, QR-Code, DataMatrix, MaxiCode
(Mode 3,4 SCM)
Table 6: Implemented Escape Sequences
4.7 Check Digits
The method for the check digit(s) calculation depends on the respective barcode type. In order to
make TEC-IT products as user-friendly as possible, a standard method for each barcode type is
supplied (where applicable).
►
Per default the input can take place with and without a check digit. In the latter case the
check digit is calculated automatically and added to the barcode data.
Example (EAN13): If you enter 12 digits (= utilizable data), the 13th digit (= the check digit) is
computed and added automatically. If you enter 13 digits, the check digit is replaced by your
data and isn‟t calculated.
Check digit enumeration
Enumeration
value
Check digit calculation methods
eCDNone
0
No check digit will be computed
eCDStandard
1
Standard check digit of the selected barcode type is used
eCDMod10
2
Modulo 10 (usually used with Interleaved 2of5)
eCDMod43
3
Modulo 43 (suggested for Code39 and Logmars, consist of 1 digit)
eCD2Mod47
4
Modulo 47 (2 digits)
eCDDPLeit
5
Method for DP Leitcode
eCDDPIdent
6
Method for DP Identcode
