Static Memory Single Read Cycle
Note: 1. The cycle time can be extended by integer multiples of the clock period (22 ns at 45 MHz, 27 ns at 36 MHz, 54 ns at
18.432 MHz, and 77 ns at 13 MHz), by either driving EXPRDY low and/or by programming a number of wait states. EXPRDY is
sampled on the falling edge of EXPCLK before the data transfer. If low at this point, the transfer is delayed by one clock period
where EXPRDY is sampled again. EXPCLK need not be referenced when driving EXPRDY, but is shown for clarity.
2. Address, Halfword, Word, and Write hold state until next cycle.
EXPCLK
nCS
A
nM W E
HALF-
W ORD
W ORD
D
W RITE
nM OE
t
CSd
t
Ad
t
CSh
t
M OEh
t
Dh
t
Ds
t
HW d
t
W Dd
t
W Rd
t
M OEd
EXPRDY
t
EXh
t
EXs
Figure 3. Static Memory Single Read Cycle Timing Measurement
