An366 – Cirrus Logic AN366 User Manual
Page 19
AN366
AN366
REV2
19
Figure 13. MTE Meter Test Equipment Calibration Hardware Setup
MTE Meter Test Equipment
AG
PTS 400.3 Modular Portable
Test System
Reference
Meter
Optical
Connection
AC
Source
Voltage Inputs
UART to PC Controller
Line Reference
Current Inputs
DUT Supply
Rogowski Sensor
USB to PC Controller
Pulse to Optical Counter
