Communication Parameters
30
13 Communication Parameters
Table 7 lists the communication parameters as used in Kramer Electronics
products.
Table 7: Communication Parameters
RS-232
Protocol 2000 Protocol 3000 (Default)
Baud Rate: 9600 Baud Rate: 115,200
Data Bits: 8 Data Bits: 8
Stop Bits: 1 Stop Bits: 1
Parity: None Parity: None
Command Format: HEX Command Format: ASCII
Example (Output 1 to Input 1): 0x01, 0x81, 0x81, 0x81 Example (Output 1 to Input 1): #AV 1>1
Switching Protocol
P2000 -> P3000 P3000 -> P2000
Command: 0x38, 0x80, 0x83, 0x81 Command: #P2000
Front Panel: Press and hold Output 1 and Output 3
simultaneously
Front Panel: Press and hold Output 1 and
Output 2 simultaneously
Ethernet Factory Default Values
IP Address: 192.168.1.39
Mask: 255.255.255.0
Gateway: 192.168.1.1
Power cycle the unit while pressing the Factory Reset button, located on the
rear panel of the unit.
TCP Port #: 5000
UDP Port #: 50000
14 Default EDID
The default EDID is stored in all inputs.
Monitor
Model name............... VP-81K-SI
Manufacturer............. KRM
Plug and Play ID......... KRM0808
Serial number............ 2
Manufacture date......... 2009, ISO week 10
-------------------------
EDID revision............ 1.3
Input signal type........ Analog 0.700,0.000 (0.7V p-p)
Sync input support....... Separate, Composite, Sync-on-green
Display type............. RGB color
Screen size.............. 360 x 290 mm (18.2 in)
Power management......... Standby, Suspend, Active off/sleep
Extension blocs.......... None
-------------------------
DDC/CI................... Not supported
Color characteristics
Default color space...... sRGB
Display gamma............ 2.00
Red chromaticity......... Rx 0.611 - Ry 0.329
Green chromaticity....... Gx 0.312 - Gy 0.559
Blue chromaticity........ Bx 0.148 - By 0.131
White point (default).... Wx 0.320 - Wy 0.336
Additional descriptors... None
Timing characteristics
Range limits............. Not available
