Parts Listings and Cross-Sectionals
Table 7: Parts List
Item Number Description Quantity
100B 1st Stage Remachine for Plan 11 takeoff (optional) 1
100D Casing (Discharge) 1
100G Diffuser Stage Casing stage dependent
100H Diffuser Final Stage Casing 1
100S Casing (Suction) 1
100X Casing (Destaging and Takeoff - Optional) stage dependent
101 Impeller (Series) stage dependent
103 Case Wear Ring (Standard Clearance) stage dependent
112 Ball Bearing (Radial) 1
113A Breather 1 ES / 2 RS
117 Bearing Sleeve (End Suction Only) 1
119 Cover (Bearing Housing) 1 ES / 2 RS
119A Cover (Bearing Housing Sump) 1 ES / 2 RS
122 Shaft 1
131 Foot 2
136A Bearing Lock Nut 1
142 Impeller Wear Ring (Optional) stage dependent
157 Bearing Spacer 2
178 Key (Impeller) stage dependent
178R Key (Balance Drum) 1
184 Seal Chamber 1
197A Bearing Bushing (End Suction Only) 1
214B Split Ring 1
222V Set Screw (Fan) On 5"(125) and 6"(150) pumps only 1
228C Bearing Housing 1 ES / 2 RS
251 Oiler (Constant Level) 1 ES / 2 RS
300 Balance Drum 1
300A Balance Drum Stator 1
332A Bearing Isolator (Outboard) 1
333A Bearing Isolator (Inboard) 1 ES / 2 RS
352F Set Screw (Retaining Ring) 1
356A Stud (Bearing Housing to Suction/Discharge Casing) 8 ES / 16 RS
356J Tie Rod 8
356Y Stud (Seal Chamber) 8
357F Nut (Tie Rod) 8
357K Nut (Seal Chamber) 8
358 Drain Plug (Casing) 3
358A Plug (Seal Chamber Flush) 2
358C Plug (Destage Casing - optional) stage dependent
358K Plug (Bearing Housing Opening) 1 ES / 2 RS
358L Plug (Balance Return) 4
358M Plug (Casing Branch Tapping) 4
361H Retaining Ring 1
371C Cap Screw (Bearing Housing Cover) 8
371S Cap Screw (Bearing Housing Sump Cover) 12
372H Cap Screw (Balance Drum Locking Plate) 3
372T Cap Screw (i-ALERT to Bearing Housing) 2
382 Bearing Lock Washer 2
383 Mechanical Seal 1 ES / 2 RS
392 Fan (Brg. Cooling) On 5"(125) and 6"(150) pumps 1
only
400 Key (Coupling) 1
409 Ball Bearing (Thrust) 1
114 Model 3393 Installation, Operation, and Maintenance Manual
