Parts Listings and Cross-Sectional Drawings
Item
Quantity Part name
Pump Material
All 317SS
All Monel
All Nickel
All
All
Hastelloy C Hastelloy B
184
1
Seal Chamber/Stuffing Box Cover
1209
1119
1601
1215
1217
193
2
Grease Fitting
Steel
228
1
Bearing Frame
STi-1013, All others - 1001
236A
10
Cap Screw—Bearing Clamp Ring
2210
239
1
Support, Casing
–
–
–
2201*
–
241
1
Frame Foot
1001
248
1
Oil Thrower
2210
250
1
Gland—Mechanical Seal
Material varies
253B
1
Bearing Clamp Ring
2210
319
1
Sight Glass
Glass/steel
332A
1
Outboard Labyrinth Seal w/O-rings
Brass ASTM B505-96
333A
1
Inboard Labyrinth Seal w/O-rings
Brass ASTM B505-96
351
1
Casing Gasket
Aramid fiber w/EPDM
353
4
Gland Stud
2232
2150
2155
2248
2247
355
4
Gland Stud Nut
2232
2150
2155
2248
2247
358
1
Plug—Casing Drain
2232
2150
2156
2248
2247
358Y
1 ***
Plug, Impeller
2232
2150
2156
2248
2156
360C
1 ***
Gasket—Thrust End Cover
Buna
360D
1
Gasket—Frame-to-Adapter
Buna
360Q
1
Gasket—Gland-to-Stuffing Box Cover Material varies
361A
1
Retaining Ring
Steel
370
****
Bolt—Adapter to Case
2228
370B
4
Bolt—Frame-to-Adapter
2210
370C
**
Clamp Bolt —Bearing Housing
2210
370D
**
Jack Bolt—Bearing Housing
2210
370F
2
Bolt—Frame Foot to Frame
2210
370H
2
Stud—Stuffing Box Cover-to-Adapter 2228
370H
2
Bolt—Cap Casing to Support
–
–
–
2210*
–
371C
6 ***
Cap Screw-End Cover to Bearing
2210
Housing
382
1
Bearing Lockwasher
Steel
383
1
Mechanical Seal
Material varies
400
1
Coupling Key
2210
408A
1
Plug—Oil Drane
2210
408H
4
Plug—Oil Mist Connection
2210
408J
1
Plug—Oiler
2210
408L
1
Plug—Oil Cooler Inlet
2210
408M 1
Plug—Oil Cooler Outlet
2210
408N
1
Plug—Sight Glass
2210
412A
1
O-Ring, Graphoil Impeller
–
–
–
*
–
418
3
Jack Bolt—Adapter-to-Case
2228
423
3
Jam Nut—Bearing Housing Jack Bolt 2210
423B
2
Hex Nut—Stuffing Box Cover to
2228
Adapter
428
1
Gasket, Plug
Teflon
437
1
Lockwasher, Casing to Support
–
–
–
2210*
–
458Y
1***
Plug, Impeller
2232
2150
2155
2248
2247
469B
2
Dowel Pin—Frame-to-Adapter
Steel
494
1
Tube Element, Finned Cooled
304SS / Copper
496
1
O-Ring Bearing Housing
Buna N
412A
1
O-Ring—Impeller
Viton
497F
1
O-Ring—Outboard Labyrinth Rotor
Viton
497G
1
O-Ring—Outboard Labyrinth Stator
Viton
497H
1
O-Ring—Inboard Labyrinth Rotor
Viton
497J
1
O-Ring—Inboard Laybrinth Stator
Viton
497L
1
O-Ring Internal (inboard)
Viton
497N
1
O-Ring Internal (outboard)
Viton
