VII. REPLACEMENT PARTS
PRICES AS OF July 1, 2001
PRICES SUBJECT TO CHANGE — contact the Myron L Company for the latest prices.
Prices are in US dollars.
PART # CIRCUIT BOARD ASSEMBLIES PRICE
XXX AQUASWITCH I & AQUASWITCH II Power Board $XXX.00
XXX AQUASWITCH I & AQUASWITCH II Logic Board $XXX.00
753 II RB ASII R RESISTIVITY Monitor/controller Circuit Board $301.00
758 II CB ASII C CONDUCTIVITY Monitor/controller Circuit Board $290.00
(Must select RANGE MODULE from RANGE SELECTION GUIDE, see page 8) NO ADDITIONAL CHARGE
24VA 24 VAC Isolated Power, add to above prices $18.00
24VD 24 VDC Isolated Power, add to above prices $45.00
If VOLTAGE is not specified 115/230 VAC will be supplied.
RANGE MODULES SELECT from RANGE SELECTION GUIDE, see page 8
RMXXX Range Module Only $16.00
RMXXXD With Overlay Labels $18.00
DIGITAL DISPLAYS
35 3 1/2 Digit without Bezel $70.00
35BL 3 1/2 Digit Backlit without Bezel $130.00
HARNESS (STANDARD 9 in./229 mm)
XX Harness, Power to Logic Board $XX.00
DH Harness, ASII R or ASII C Monitor/controller $73.00
E N C L O S U R E
AS I EC AQUASWITCH I Rear Housing (BOX) $36.00
AS II EC AQUASWITCH II Rear Housing (BOX) $XX.00
FRONT PANEL with UPPER and LOWER LABELS ONLY
ASIFP AQUASWITCH I Front Panel $60.00
ASIIFP AQUASWITCH I I Front Panel $XX.00
OPTI O N S & A C CESSO RIE S
4AMO 4-20mA Self-Powered Isolated Output Module $108.00
4AH Harness, 4A (4-20mA) $32.00
TPMO Temperature Module 0-200°C $116.00
TPAMO Above Temperature Module with Adjustable Hysteresis (SPECIAL ORDER) $118.00
TDH Harness, TP and TPA (Temperature Module) $44.00
TPC Calibration Module (Temperature Module) $119.00
F100 Fuse, 115/230 VAC Monitor/controller & Power Board (late), 100mA (T.10A) 5 X 20 Slow Blow/Time Delay $2.00
F250 Fuse, 24 VAC Monitor/controller & Power Board (late), 250mA (T.25A) 5 X 20 Slow Blow/Time Delay $2.00
F18 Fuse, 115/230 VAC, 1/8 amp, AGC 1/8, Power Board (early - with open fuse) $1.12
024-1 24 VAC 1” Solenoid Valve $65.00
42
