29
POLYMER
MENU POLY START DELAY NUMBER FROM 0 TO 255
USING UP AND DOWN
ARROWS. ENTER TO
FINISH 2 0 255 Seconds
POLYMER
MENU PUMP STOP DELAY NUMBER FROM 0 TO 255
USING UP AND DOWN
ARROWS. ENTER TO
FINISH 0 0 255 Seconds
MIXER
MENU MIX START DELAY NUMBER FROM 0 TO 255
USING UP AND DOWN
ARROWS. ENTER TO
FINISH 2 0 255 Seconds
MIXER
MENU MIX STOP DELAY NUMBER FROM 0 TO 255
USING UP AND DOWN
ARROWS. ENTER TO
FINISH 2 0 255 Seconds
ALARM
MENU ALARM DELAY TIME TIME THE SYSTEM WILL
OPERATE PRIOR TO
RECOGNIZING A
PENDING ALARM.
NUMBER FROM 0 TO 255
USING UP AND DOWN
ARROWS. ENTER TO
FINISH 10 0 255 Seconds
RELAY
OUTPUTS RELAY 1 CONFIG OPTIONS: Run/Stop
Indication, Local Remote
Status, Low Water, Low
Polymer Run/Stop N/A N/A N/A
RELAY
OUTPUTS RELAY 2 CONFIG OPTIONS: Run/Stop
Indication, Local Remote
Status, Low Water, Low
Polymer Local
/Remote N/A N/A N/A
RELAY
OUTPUTS RELAY 3 CONFIG OPTIONS: Run/Stop
Indication, Local Remote
Status, Low Water, Low
Polymer Low Water N/A N/A N/A
SENSOR
INPUTS POLY FLOW SWITCH Inactive, Normally Open,
Normally Closed Inactive N/A N/A N/A
SENSOR
INPUTS WATER FLOW
SWITCH Inactive, Normally Open,
Normally Closed Normally Open N/A N/A N/A
POLY
CALIBRAT-
ION CALIBRATION
ROUTINE IMPLEMENTS ROUTINE
TO CALIBRATE THE
POLYMER PUMP. NO
PARAMETERS TO
CHANGE OTHER THAN
CAPACITIES AT 25%, 50%,
75% & 100% 64,140,219,280 NA NA CC/min
ANALOG IN 0% LEVEL ONLY THE ENTER
BUTTON IS ACTIVE.
MINIMUM PROCESS
SIGNAL NEEDS TO BE
SENT INTO THE SYSTEM 201 NA NA Counts
ANALOG IN 100% LEVEL ONLY THE ENTER
BUTTON IS ACTIVE.
MAXIMUM PROCESS
SIGNAL NEEDS TO BE
SENT INTO THE
SYSTEM 1012 NA NA
