11
6.4 Fastener and Fitting Inspection
All system fasteners should be checked prior to pump operation, and occasionally during use. This
would include:
 The mix chamber tie-rods
 Motor mounting bolts
 Hardware that secures the pipe clamps to the frame
 All piping unions and connection points
Most hardware can be checked simply to ensure it is not loose. However, utilize the following values
when checking the mix chamber hardware:
Mix Chamber
Tie Rods
Fastener Torque
# Fasteners and size N-m In. - Lbs
(16) 3/8-16 Hex Nut 3.4 30
Motor Bolts (4) 3/8-16 x 1.75 SHCS 3.4 30
Table 6-4 Fastener Torques
