SCPI Command Reference

136

N9340A User’s Guide

TRACe Subsystem

The TRACe subsystem controls access to the
internal trace memory of the analyzer.

Select Trace Display Mode

This command selects the display mode as follows:

• Write

Puts the trace in the normal mode, updating the
data.

• Maximum Hold

Displays the highest measured trace value for all
the data that has been measured since the func-
tion was turned on.

• View

Turns on the trace data so that it can be viewed
on the display.

• Blank

Turns off the trace data so that it is not viewed
on the display.

*RST State:

Write

Key Access:

[TRACE] > {Clear Write}

[TRACE] > {Max Hold}

[TRACE] > {Min Hold}

[TRACE] > {View}

[TRACE] > {Blank}

NOTE

Whenever the number of sweep points change, the
following functions affected:

• All trace data is erased

• Any traces in view mode will go to blank mode.
