SCPI Command Reference

112

N9340A User’s Guide

DISPlay Subsystem

The DISPlay subsystem controls the selection and
presentation of textual, graphical, and trace
information. Within a display, information may be
separated into individual windows.

Turn the Entire Display On/Off

:DISPlay:ENABle OFF|ON|0|1

This command turns the display on or off. Having
the display turned off may increase repetitive
measurement rate.

Trace Y-Axis Scaling

:DISPlay:WINDow:TRACe:Y[:SCALe]
:PDIVision 1|2|5|10
:DISPlay:WINDow:TRACe:Y[:SCALe]
:PDIVision?

This command sets the per- division display scaling
for the y- axis when y- axis units are set to
amplitude units.

*RST State:

*RST Value:

10 dB

Range:

1 dB, 2 dB, 5 dB or 10 dB

Key Access:

[AMPTD] > {Scale/DIV}
