SCPI Command Reference

N9340A User’s Guide

101

CALCulate Subsystem

This subsystem is used to perform post- acquisition
data processing. In effect, the collection of new
data triggers the

CALCulate subsystem. This

subsystem is further divided into two subsections:
limits and markers which are the primary
functions in this subsystem.

CALCulate:LLINe Subsection

A N9340A allows you to define a limit line for your
measurement. You can then have the instrument
compare the data to your defined limit and
indicate a pass/fail condition.

Delete All Limit Lines in Memory

:CALCulate:LLINe:ALL:DELete

This command deletes all limit lines in volatile
memory.

Select the Type of Limit Line

:CALCulate:LLINe[1]:TYPE UPPer|LOWer
:CALCulate:LLINe[1]:TYPE?

This command sets a limit line to be either an
upper or lower type. An upper line will be used as
the maximum allowable value when comparing
with the data. A lower limit line defends the
minimum value.

NOTE

Refer to : TRACe subsystem for more trace commands.

Key Access:

[Limit] > {Limit Mode}

*RST State:

Upper

Range:

Upper|Lower

Key Access:

[Limit] > {Limit Mode}
