Front Panel Operation
Setup Menus
Selftest Menu
Press the
Shift
key and the
Menu
key. The selftest menu is displayed. The menu is
used to execute the selftest and diagnostics.
Press the arrow key to move the cursor to the desired function name. Then, press the
Enter
key. The setup message or the sub menu will be displayed. To return to the
previous menu, press the
Exit
key.
Function Tree
This menu provides the following functions.
•
SELFTEST
Executes the controller test or displays test result.
•
RELAY_TEST
Executes the relay test or displays test result.
•
KEY
Executes the front panel interface test or displays test result.
•
BEEPER
Executes the beeper test or displays test result.
•
LED
Executes the LED matrix test or displays test result.
•
PEN
Executes the light pen test or displays test result.
•
GPIB
Executes the GPIB test or displays test result.
[Execute Diagnostics]
SELF_TEST
RELAY_TEST
KEY
BEEPER >
[Execute Diagnostics]
BEEPER LED PEN GPIB
