2-24 Agilent B2200 User’s Guide, Edition 2
Installation
Measurement Cable Length
Table 2-8 Guard Capacitances of B2200 Measurement Environment (Typical)
Connection Agilent Model/Part No.
Cable
Length
Guard
Capacitance
from SMU to B2200
inputs 16494A-003 (for non-Kelvin) 80 cm 75 pF
16494A-001 (for non-Kelvin) 1.5 m 130 pF
16494B-003 (for Kelvin, 4142B) 80 cm 90 pF
16493K-001 (for Kelvin) 1.5 m 150 pF
mainframe and
modules B2210A (only 1 card is installed) − 145 pF
B2210A (more 1 card) − 8 pF/extra card
B2211A (only 1 card is installed) − 145 pF
B2211A (more 1 card) − 8 pF/extra card
from B2200 outputs
to connector plate or
probe card interface 16494A-001 (for non-Kelvin) 1.5 m 130 pF
16494A-002 (for non-Kelvin) 3 m 240 pF
16494A-003 (for non-Kelvin) 4 m 340 pF
16494B/C-001 (for Kelvin) 1.5 m 140 pF
16494B/C-002 (for Kelvin) 3 m 260 pF
16494C-003 (for Kelvin) 4 m 340 pF
from connector
plate to DUT Agilent Part No. 8121-1191 X m 130 pF per m
probe card interface B2220A − 70 pF
