1-6 Agilent B2200 User’s Guide, Edition 2
Introduction
Rear Panel
Rear Panel
The Agilent B2200 series has four card slots for the switch modules, the GPIB
interface and so on.
• Card slots
For the Agilent B2200A mainframe, the Agilent B2210A cards are installed.
For the Agilent B2201A mainframe, the Agilent B2211A cards are installed.
Mixed configuration of the switch modules is not supported.
• GPIB interface
Use an Agilent 82357A USB/GPIB interface or Agilent 10833A/B/C/D GPIB
cable to connect to an external computer or equipment.
• Serial number
You need this serial number when using the Agilent Technologies telephone
assistance program.
• LINE input receptacle
AC power cable is connected to this receptacle.
