Agilent B2200 User’s Guide, Edition 2
5-11
SCPI Command Reference
*STB?
The following is example for query:
OUTPUT @Agb2200;"*SRE?"
ENTER @Agb2200;A
*STB?
This query command reads the Status Byte Register (reads Master Summary Status
bit, not Request for Service Message).
For bit6, this command reads MSS, not Request for Service (RQS). See “Status
Reporting Structure” on page 5-53.
Syntax
*STB?
Query response
register
Semantics
The following table shows the bits of the Status Byte Register, and the
binary-weighted decimal value of each bit.
Example
OUTPUT @Agb2200;"*STB?"
ENTER @Agb2200;A
Parameter Explanation
register
decimal integer value that is the sum of the binary-weighted values
for the set bits
bit binary-weight
description
0
1
not used. always 0.
1
2
not used. always 0.
2
4
not used. always 0.
3
8
not used. always 0.
4
16
MAV (Message Available summary-message)
5
32
ESB (Event Status Bit)
6
64
MSS (Master Summary Status)
7
128
not used. always 0.
