Agilent Technologies Agilent 4396B User Manual
Page 66

Step
4:
Reading
a
Measurement
Result
Y
ou
may
want
to
readout
the
measured
values
on
the
displayed
trace
.
Y
ou
can
use
the
marker
function
for
this
purpose
.
The
marker
shows
the
frequency
and
response
value
at
the
marker
point.
Reading
a
Measured
V
alue
by
Using
Marker
In
the
MARKER
block,
press
4
Marker
5 .
V
erify
a
marker
appears
on
the
trace
.
Turn
the
knob
to
the
right
to
move
the
marker
toward
the
right.
Read
the
values
at
the
right
top
of
the
display
.
The
marker
has
a
search
function
that
makes
it
easier
and
faster
to
evaluate
the
trace
results
.
F
or
example
,
to
search
for
the
maximum
value
and
its
frequency
on
the
trace:
3-12
Network
Analyzer
T
our
