Specifications
General
Wireless
Standards compliance IEEE 802.11, 802.11b Direct Sequence Spread Spectrum - DSSS
RF frequency range Range 2.4 to 2.4835 GHz, 2.4 to 2.497 GHz for Japan
Data rate Auto, 11, 5.5, 2, and 1 Mb/s
Modulation Auto 11 and 5.5 Mb/s = CCK,
2 Mb/s = DQPSK,
1 Mb/s = DBPSK
Number of channels Europe = 13, Spain = 2, France = 4, US = 11, Japan = 14
Transmit power 17.5 dBm (EIRP)
Receive sensitivity -83 dBm at 11 Mbps
Router
Ethernet standards
compliance IEEE 802.3, IEEE 802.3u
Number of ports 5
Number of uplink ports 5
Electrical
Input voltage range 100 – 240 VAC, 50 – 60 Hz
Power consumption 18 Watts
Print Server Windows, Macintosh, Linux
Environmental
Operating temperature 0° C – 40° C, -150 to 10000 ft.
Storage temperature -30° C to 80° C
Humidity 5 to 95% RH, non-condensing
Mechanical antenna Two external articulating antennas, with unique connectors per FCC requirements
LED indicators
Modem Receive, Send, Online, Internet
Router (each port 1 – 5) Activity, 10/100, Half/Full, Link
Access point Wireless
Other USB, Power, Model Number
Interfaces (1) AC Power, (1) F-Type, (5) RJ-45, (2) RJ-11, (1) DB-25
Dimensions 290 W x 160 D x 70 H (mm)
Weight 0.8 lbs (unit only)
