Front-Panel Lights and Error Conditions

Light

Turns Off During Startup If

Turns Off During Normal Operation If

RX (receive)

The receive channel cannot be acquired

The receive channel is lost

TX (transmit)

The send channel cannot be acquired

The send channel is lost

LNK (link)

IP registration is unsuccessful

The IP registration is lost

Power

The

SBG1000

is not properly plugged into the

power outlet

The

SBG1000

is unplugged
