Fargo DTC1000/DTC4000/DTC4500 CUPS Driver User Guide - LINUX (L001452, Rev 1.2) 41
Defining Overlay/Print Area Options
If custom print areas should be excluded from the print, this can be done with defined areas.
To use these custom areas, PrintAreaFrontOption or PrintAreaBackOption must be set to
defined or undefined areas.
Select defined to exclude all defined areas from the print. Select undefined to exclude
all undefined areas from the print.
Five (5) areas can be defined. The only way to define these areas is via the command
line interface. (Note: This is because these parameters are too complex for the cups
interface. Use 2,3,4 or 5 instead of 1 to address the other print areas.)
To define a print area set Origin X and Y and Length X and Y. Remember that Origin,
Length and Origin + Length must be in the printable area.
The printable area is from 0/0 to 152/242 for CR80 and from 0/0 to 148/238 for CR79.
Command Line Usage CUPS option Description
PrintAreaFrontEnable1 =
true/ false n/a Select if print area front 1 should be
enabled.
PrintAreaFrontXOrigin1 = X n/a Sets the X origin for print area front 1.
PrintAreaFrontYOrigin1 = X n/a Sets the Y origin for print area front 1.
PrintAreaFrontXLength1 = X n/a Sets the X length for print area front 1.
PrintAreaFrontYLength1 = X n/a Sets the Y length for print area front 1.
PrintAreaBackEnable1 =
true/ false n/a Select if print area back 1 should be
enabled.
PrintAreaBackXOrigin1 = X n/a Sets the X origin for print area back 1.
PrintAreaBackYOrigin1 = X n/a Sets the Y origin for print area back 1.
PrintAreaBackXLength1 = X n/a Sets the X length for print area back 1.
PrintAreaBackYLength1 = X n/a Sets the Y length for print area back 1.
