Swiftech H20 120 R3A - Manual (Page 8)

Copyright Swiftech 2005 – All rights reserved – Last revision date: 7-28-05
Radiator Assembly Dimensions - Part # MCR120-FK Radiator Assembly Dimensions - Part # MCR120-FK
Thickness Height Core width Inlet Outlet tube size
2.4"
(60mm)
6.2"
(158mm)
5.00"
(134mm)
Built-in 3/8" hose barbs
Fan Specifications - Part # WFB1212M
Voltage
(V)
Current
(mA)
Speed
(RPM) Volume
(CFM)
Static pressure
(InH20)
Sound Noise
(dbA)
7.0-13.8 .20 2100 72.4 .134 34
2. W ATER - BLOCK ( S ) I NSTALLATION
When provided in kit form, the MCW6000 series water-blocks receive 2 ft. of pre-installed tubing at the inlet and outlet. In dual processor kits, one of
the water-blocks inlets is free of tubing so that water-blocks may be installed in series. Please refer to your specific water-block model installation guide
provided in appendix to proceed with the installation of the water-block to your motherboard.
- Information subject to change without notice – URL: http://www.swiftnets.com
Rouchon Industries, Inc., dba Swiftech – 1703 E. 28 th Street, Signal Hill, CA 90755 – Tel. 562-595-8009 – Fax 562-595-8769 - E Mail: [email protected] PAGE 8 of 38
TIP!
For the mock-up installation, interposing a piece of
paper between the water-block and the processor will protect
both the cooler and the processor surfaces.
