Installation Instructions
B190
For Antasia Sconce 20-4712L & 20-4112R Page 3 of 3
Hand-Forged, Vermont-Made Lighting and Accessories
P.O. Box 827, 154 Route 30 South, Castleton, Vermont 05735 22864
To Install Glass (Figure 2)
Component Parts
I Socket
J Bulb
(included)
K Retaining Ring (2)
L Inner
Glass
M Outer Glass
N Socket Tool
O Spacer
1. Remove retaining rings (K) from socket (I). Retaining rings are shipped
installed.
2. Install light bulb (J). Be careful not to touch bulb with bare hands; oil from
the hands will dramatically reduce bulb life.
3. Slip outer glass (M) and spacer (O) (oriented as shown in Figure 2) over
socket (I). Thread one of the retaining rings onto the socket using socket tool
(N) provided. Note: Flat side of retaining ring should be oriented as shown.
4. Slip inner glass (L) over socket (I).
5. Thread retaining ring (K) onto socket (I) using socket tool (N) until snug
against inner glass (L). Be careful not to over tighten.
Note: Flat side of retaining ring should be oriented as shown.
6. Restore electricity at the main breaker.
If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased
this product. We hope you enjoy your fixture!
* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.
(Figure 3)
