Assembly & Installation Instructions
A217
For Ellipse Large Nine Light Pendant 13-7531 & 13-7531E Page 3 of 4
Hand-Forged, Vermont-Made Lighting and Accessories
P.O. Box 827, 154 Route 30 South, Castleton, Vermont 05735 22896
Install Glass on G9 Version (Figure 6)
Component Parts
Q Bulb Shield (9)
R Bulb (supplied) (9)
S Washer
(9)
T Glass (9)
U Socket (9)
1. Install bulb (supplied). Be careful not to touch bulb with bare
hands; oil from the hands will dramatically reduce bulb life.
2. Place glass (T) over socket (U).
3. Place washer (S) over socket (U) until it rests on the bottom inside
of glass (T).
4. Thread bulb shield (Q) onto Socket (U). Future bulb changes may
be accomplished by snapping glass bulb shield on and off rather
than unthreading the holder.
5. Restore electricity at the main breaker.
(continued)
(Figure 6)
(Figure 5)
