Assembly & Installation Instructions
A246
For Adjustable Mobius Shade Pendant 13-4505 Page 4 of 7
Hand-Forged, Vermont-Made Lighting and Accessories
P.O. Box 827, 154 Route 30 South, Castleton, Vermont 05735 24615
Step 2 Fold shade panel over and
align letter designations “C”.
Note: Top letter "C" should be
oriented the same as the
bottom letter "C".
Step 3 Slip bracket with studs (Q) through the “C”
sides of the flat shade panel (P).
Step 4 Flip over flat shade panel (P) and slip shade
spider (L) onto the studs as shown.
(continued)
