Chapter 3
Configuring the Management Module
After you have installed the AT-MCM02 Management Module in the media
converter, you must assign it an IP address, a subnet mask, and a gateway
address. You must also connect the management module to the network.
Note
You must perform this procedure if you intend to manage the media
converter using Telnet or SNMP. This procedure is not necessary if you
will be managing the media converter only through the RS-232 port on
the front panel of the media converter.
To configure the management module, perform the following procedure:
1. Connect the miniDIN end of the control cable to the Management RS-232
port on the front panel of the media converter.
2. Connect the other end of the control cable to a DB9 (male) connector on a
terminal or a PC with a terminal emulation program.
3. Configure the terminal or the terminal emulation program to the
following settings:
❑
Baud rate: 38400
❑
Parity: None
❑
Start bits: 1
❑ Stop bits: 1
❑
Flow control: None
❑
Emulator: VT100
