Allied Telesis AT-VIEW PLUS 3.2 DEVICE MANAGER - Manual (Page 77)

Allied Telesyn AT-VIEW PLUS
DEVICE MANAGER
Displays a value as it is.
Relative
Displays a change in the value per second. This is (Current value - Previous value) /
Polling Interval.
Note - The change here takes effect the next time the data is polled.
6.5.3 Regist Menu
Add this window to the User Menu. If you want to view the current window repeatedly, do the
following.
1. Click "Regist menu".
2. On "Regist Menu Item" dialog box, select one of "Common Menu" or "Target Menu".
Common Menu is always accessible regardless of the target device. Target Menu can be
accessed only when connected to the same specific device type.
3. Optionally, change the MenuItem Name. This string is displayed as the menu item name.
4. Click OK.
6.5.4 Save Polling Data
Save the collected data to a file. When you click this button, the Polling Data Save dialog box
appears and lets you specify the name of the file and the file format. To start saving data, click
OK in the Save Polling Data dialog box. The Save polling data button changes to "Saving polled
data". To close the file and stop saving data, click this button again.
The file format can be selected from the following options:
CSV Format
Save data in comma-separated values (CSV) format.
TAB Format
Save data in Tab-separated values (TSV) format.
Save polling data
PN 613-50664-00 Rev C Page 77 of 119
