Allied Telesyn AT-VIEW PLUS
DEVICE MANAGER
Falling Event Index
The index of the RMON Event entry which is triggered when the sampled value falls
below the falling threshold.
7.4.2 Event Table of Alarm
"Event Table of Alarm" shows a list of events for the Alarm entry which is selected in the Alarm
Table. You can check which type of events are configured for a specific alarm entry.
Index
The index number used to identify the Event entry.
Event Description
Text describing the Event entry.
Event Type
The type of action to be taken if the event occurs. Select one of "none" (no action taken),
"SNMP trap" (send out an SNMP trap), "log" (record to the log) and "log & SNMP trap"
(record to the log and send out an SNMP trap).
TRAP Community
Trap Community name.
Last Sent Event Time
The value of sysUpTime at the time when the last event occurred.
Status
The status of the Event entry.
Owner
The owner (creator) of the Event entry.
7.4.3 Add Button
: adds a new entry to the table. Click this button to open the Add Alarm Table Entry dialog
box, enter parameters for the Alarm Table entry, and click OK to add the new entry.
Note - If you specify an SNMP trap action, trap hosts must be configured in the RMON agent.
Trap hosts cannot be configured by AT-View Plus Device Manager. Use other means, such as a
console terminal, Telnet or Web interface to set up SNMP trap hosts on the agent.
Note - If you configure the station running AT-View Plus Device Manager as the trap host, use
the same Trap community name configured in the Target Host Property dialog box (File >
Properties).
PN 613-50664-00 Rev C Page 110 of 119
