Allied Telesyn

AT-VIEW PLUS

DEVICE MANAGER

6.1 Table Tab

In the Table tab, MIB variables are displayed in a table. This is the default tab opened by a menu
item. Values in the table are updated at each polling interval.

Note

- The type of variables displayed determines which kind of tabs are displayed and which are

not. For example, chart tabs are not displayed when you are only viewing string variables.

Note

- SNMPv3: Depending on the READ VIEW access settings of the User Account Name

used, there is a possibility that AT-View Plus Device Manager may not be able to access some
MIB values. When this happens, the table will display a blank cell for those MIB values.

Topic:

•

Transpose Button

Table tab

6.1.1 Transpose Button

: flips rows and columns.

6 MIB Variable Window

PN 613-50664-00 Rev C

Page 66 of 119
