Allied Telesyn AT-VIEW PLUS
DEVICE MANAGER
Min Value
Shows the lowest value of each variable after the current history control entry is selected
at the Entry tab.
Average Value
Shows the average value of each variable after the current history control entry is selected
at the Entry tab.
XXXXXX
Sample Index. A maximum of the 40 latest index numbers are displayed.
7.3.4.2 Sort
To sort table items, click a column title. When you click the column title, table items are sorted
by the column in ascending order. One more click sorts the items in descending order. To restore
the original order, click the Reset Table button.
7.3.4.3 Reset Table Button
: Reorders table items to their original order after sorting.
7.3.5 Plot Chart Tab
In the RMON History Plot Chart tab, RMON history information is displayed in a time-scaled
plotted graph. Data is updated at the polling interval. The horizontal axis holds a maximum of the
40 latest data values.
Topics:
• Popup Display
PN 613-50664-00 Rev C Page 101 of 119
