Allied Telesis AT-VIEW PLUS 3.2 DEVICE MANAGER - Manual (Page 115)

Allied Telesyn AT-VIEW PLUS
DEVICE MANAGER
Index
The index number used to identify the Event.
Event Description
Text describing the Event entry.
Event Type
The type of action to be taken when the event occurs. Select one of "none" (no action
taken), "SNMP trap" (send an SNMP trap), "log" (record to the log) and "log & SNMP
trap" (record to the log and send an SNMP trap).
TRAP Community
The Trap Community name.
Last Sent Event Time
The value of sysUpTime at the time when the last event occured.
7.5.2 Select Button
: selects an Event entry to be displayed in the Event Log tab. In the Event Log tab, only log
entries related to the selected Event Index are displayed.
7.5.3 Add Button
: creates a new Event entry. Click this button to open a dialog box for a new entry. Specify
options, then click OK to add the new entry to the table.
Add Event Table Entry dialog box
PN 613-50664-00 Rev C Page 115 of 119
