Allied Telesis AT-VIEW PLUS 3.2 DEVICE MANAGER - Manual (Page 72)

Allied Telesyn AT-VIEW PLUS
DEVICE MANAGER
6.4 Edit Tab
In the Edit tab, you can change the value of any variable with read-write access. All variables are
displayed in a table. For variables which can be changed, a checkbox is displayed in the first
column. To change a value, input or select a new value in the MIB Value column, check the
variable, then click the Set MIB Value button.
Topics:
• Checkbox Column
• MIB Variable Column
• MIB Value Column
• Select All Button
• Clear Button
• Reverse Button
• Get MIB Value Button
• Set MIB Value Button
• Threshold Button
Edit tab
In the Edit tab, variables are shown in a table. The table has the following columns (fields) for
each entry.
PN 613-50664-00 Rev C Page 72 of 119
