Allied Telesyn

AT-VIEW PLUS

DEVICE MANAGER

To set a threshold, enter a threshold value in the Value field, then click OK. Note that this
specifies a rising threshold which triggers an event when the variable's value increases to exceed
the threshold, i.e. crosses the threshold from below.

When the threshold is reached, a pop-up message is displayed or a predefined command is
executed. You can select which action is executed in the Option > Option > User Action tab.

Note

- Thresholds can only be used for variables of type GAUGE, INTEGER, COUNTER,

GAUGE32, INTEGER32, COUNTER32, or COUNTER64.

6 MIB Variable Window

PN 613-50664-00 Rev C

Page 75 of 119
