Environment Selecting a Site
1-3
Telesyn x400 - Installation Guide (Installation of ATI 9400)
FIGURE 1-2 ATI 9400 Fully Configured
1.2 Selecting a Site
Before installing the ATI 9400, prepare the site to ensure the product will operate in the correct environment, all
materials meet specifications, and all installation tasks can be performed.
1.2.1 Environment
The ATI 9400 is installed in a central office environment that is affected by the existing installed equipment and
the specific requirements of the ATI 9400 shelf. Refer to Table 1-2.
TABLE 1-2 Site Requirements for ATI 9400, Office Installation
Type Description
Access To be installed in a restricted access location.
Rear Access None required.
PULL
FAUL
T
INSERV
ADSL 16
TN-100-ATN-100-A
A
A
B
C D E F G H
H
I
Slot Numbers
