Installing the FPH Configure Local Terminal or PC
1-23
Telesyn x400 - Installation Guide (Installation of ATI 9400)
1.17 Configure Local Terminal or PC
The RS-232 (CONSOLE) terminal port is used during the initial installation startup to connect the ATI 9400 to a
local management device, which can be:
• A terminal (VT-100 compatible)
• A PC with terminal emulation software
The CONSOLE port is a DB9 female socket configured as a DCE, which allows for the direct connection to the
terminal or PC. Refer to 2.9.1 for a listing of DB9 pin assignments.
The settings for the CONSOLE port are initially configured with the following default values
Note: When using the CONSOLE port, ensure that the terminal emulation software has FLOW
CONTROL disabled.:
1. Connect the RS-232 cable from the terminal or PC to the ATI 9400 TERM port.
2. If the device is a PC, bring up the terminal emulation window.
TABLE 1-7 Default Asynchronous Port Settings
Option Default Option Default
ATTENTION BREAK MAXOQLEN 0 (Unrestricted)
CDCONTROL IGNORE MTU 1500
DATABITS 8 NAME ASYN 0
DEFAULTSERVICE FALSE OUTFLOW HARDWARE
DTRCONTROL ON PAGE 22
ECHO ON PARITY NONE
FLOW HARDWARE PROMPT DEFAULT (CMD>)
HISTORY 30 SECURE ON
INFLOW HARDWARE SERVICE NONE
IPADDRESS NONE SPEED 9600
IPXNETWORK NONE STOPBITS 1
LOGIN ON TYPE VT100
When using an AC-powered terminal or PC, use an RS232 line isola-
tion unit between the terminal/pc and the RS232 port. For battery-
powered devices (laptop) this is not required.
