Allied Telesis 9400 iMAP User Manual
Page 14
Install Cards into Chassis
Install the FM7
Telesyn x400 - Installation Guide (Installation of ATI 9400)
1-10
FIGURE 1-4
Front of the FM7 Showing the Lock Latch
FIGURE 1-5
FM7 with lock-latch open, partially inserted
3.
Slide the assembly into the center of the shelf until it is flush with the shelf surface, applying firm pressure
until fully seated. See Figure 1-6
