Allied Telesis 9400 iMAP User Manual
Page 26
Install Filler Plates
Installing the FPH
Telesyn x400 - Installation Guide (Installation of ATI 9400)
1-22
1.
Hold the FPH card securely and slowly but firmly push the card into the slot until the latch begins to engage
the locking rail
2.
Close the latch until the card locks into place.
The placement of filler plates is dependent upon the configuration of the 9400 system. The following table illus-
trates the differences between the two configurations.
TABLE 1-6
Single or dual network module configuration and installation of filler plate half (FPH)
System Configuration
Network Module Location
Location of filler plate
One network module
Half slot 0 (recommended)
Half slot 1
Two network modules
Half slot 0 and 1
None
