Installing the FPF Install the SFP Module
1-21
Telesyn x400 - Installation Guide (Installation of ATI 9400)
6. Close the latch until the card locks into place.
1.15 Install the SFP Module
The Small Form Factor Pluggable modules (LX or SX), which are inserted in the NM cards, can be ordered from
your ATI representative. The 850 model usually has a latch on the top that locks into place when it is fully seated.
(This latch is pushed in to eject the SFP.)
1.16 Install Filler Plates
1.16.1 Installing the FPF
For the ATI 9400, FPF are installed in empty service module slots. To install the FPF:
1. Hold the FPF card securely and slowly but firmly push the card into the slot until the latches begin to engage
the locking rail.
2. Close the latches until the card locks into place.
1.16.2 Installing the FPH
For the ATI 9400, FPF are installed in empty service module slots. To install the FPH:
The FPF and FPH are needed to keep dust from entering the chassis
and to ensure proper airflow. The shelf may overheat or become dam-
aged if these are not properly installed in every unused slot.
Do not allow the metal plate to touch the components of neighboring
cards.
While inserting the FPF and FPH, be careful not to get fingers pinched
between cards.
TABLE 1-5 9400 system configuration and installation of filler plate full (FPF)
System Configuration Service Module Location Location of filler plates
9400 system 6, 8, 10 (left) and 5, 7, 9,11 (right) Empty Service Module slots
