1-1
Telesyn x400 - Installation Guide (Installation of ATI 9400)
1. Installation of ATI 9400
1.1 Overview
1.1.1 ATI 9400 Configuration
The ATI™ 9400 is a rack-mounted shelf with a configuration that depends on customer requirements. Table 1-1
lists the components of the ATI 9400 and how they are configured. Use the letters in this table and refer to Figure
1-2 to see where the ATI 9400 components are located.
FIGURE 1-1
ATI 9400 Fully Configured
PULL
FAUL
T
INSERV
ADSL
16
TN-100-ATN-100-A
